Repeating Crossbow Plans
Plans for building a working Repeating Crossbow
Build a Repeating Crossbow with our easy, step by step plans and instructions.
When complete, the repeating crossbow measures 32 inches long and will
fire up to 10 bolts in as little as 8 seconds without reloading.
Based on the ancient Chinese
Repeating Crossbow, our crossbow uses modern materials, including a
bungee cord for a bow, to ease construction while maintaining a historically
correct mechanism and action.
Easy to Build
All TrebuchetStore.com plans
use common, inexpensive and easy to find building materials, available
at your local hardware store or home center. Basic skills and tools are
required, but the straightforward designs require no complicated layout
The Repeating Crossbow plans come complete with:
All the information you need to complete your project quickly and easily.
Parts Shopping List
Measured Drawings and Dimensions for all parts
Step by Step Assembly Instructions
Step by Step Operating Instructions
